Product Description:
Working Principle of induction melting furnace
It is an electric&magnet induction principle, electricity
generate magnet and magnet generate electricity, resonance occurs
between induction ring and capacity inside the power supply
cabinet, then alternating current is generated under the action of
resonance, then alternating current produces alternating magnetic
field, alternating magnetic field makes electrons inside the metal
material move in alternating direction, then electron eddy is
produced, electron fiercely knock with each other, so heat is
produced and heating temperature gradually increase inside the
furnace until it reach the melting point of metal.
Features:
Advantatges of Thyristor Serial-connected Resonant Medium Frequency induction
melting Furnace:
1.First, it offers saving effect in power. This thyristor
serial-connected electric furnace is currently most widely applied
in the casting industry due to its outstanding power factor of 0.95
and power saving much higher than parallel-connected thyristor
types, power saving is up to 20%.
2. Moreover, it provides excellent performance with its high safety
,durability and reliability. It has no special working environment
requirements, besides, it is provided with various protective
measures such as water pressure and temperature detection for water
pipeline.
In addition, its fast melting speed combined with low power
consumption is a great advantage . And it has a very low failure
rate and no malfunctions happen to this system within five years,
this is the reason for its great success in the industry.
Finally, it has already been designed and fabricated with mature
technology with no high harmonics and maximum power factor up to
95%, eliminating the need for power compensation and harmonic
elimination devices.
Technical Parameters:
Induction melting furnace power supply, thyristor serial-connected
inverter medium frequency power supply , one power supply cabinet
drives two furnaces
| Type | DX-3500Kw |
inlet power supply ( V) | 660V/ six phases |
inlet current ( A) | 1530 |
Direct current voltage (V) | 1800 |
Direct current (A) | 1900 |
medium frequency voltage (+-10%) V | 2900 |
medium frequency (Hz) | 100-300Hz |
medium frequency power (Kw) | 3500KW |
Applications:
Wide Applications in Many Casting Industry
lots of casting and foundry companies have already adopted this
furnace metal melting furnace for melting metals such as copper,
aluminum, iron and steel, etc., and it is proven that it is really
a very ideal melting equipment for all casting companies.
In this system, one power supply cabinet can drive not only one
furnace , but also two furnaces or multiple furnaces as well at the
same time, the power cabinet powered the two furnace synchronously
, one furnace is applied for insulation while the other furnace is
applied for melting the metal, of course, the two furnaces can also
perform melting work at the same time.
Customization:
Huarui induction melting furnace system is designed for melting
different kinds of metal. It is featured with energy-saving, fast
melting speed, reliable and easy operation, low maintenance and
high durability. Huarui provides induction melting furnaces with
model number from 0.5tons to 20tons. Each product is certified with
our own patent, national testing report, and quality management
system certificate. The minimum order quantity is 1 set, and the
price is to be negotiated. Packing details is water proof for
ensuring product safety. Delivery time is 30~45 days. Payment terms
are available for T/T or L/C. We can provide up to 1000000 sets per
year.
Support and Services:
We offer technical support and services for our Induction Melting Furnaces. Our experienced team can
provide you with advice on how to maintain and troubleshoot your
furnace. We also provide detailed instruction manuals and videos on
how to operate and maintain your furnace.
We also have a 24/7 support line that you can call anytime for assistance with any issues that may
arise with your furnace. Our team of experts are always on hand to
answer any questions you may have and provide solutions to any
problems.
We provide regular maintenance to ensure that your furnace is running at its best performance.
Our team of technicians are experienced in service for induction
melting furnaces and can provide you with the necessary maintenance
work to keep your furnace running safely and efficiently.
We also offer emergency repair services if any major issues arise with your furnace. Our technicians are
available at any time for you
